System 2000
Structural snap-lock panel
The System 2000 metal roof panel is a structural 1-3/4" integral snap-lock metal roof system, providing a weathertight joint without the use of a mechanical seamer. This metal roof panel has excellent structural spanning capabilities. The snap-lock design allows for installation efficiency and weathertight protection.
Profiles
PRODUCT DATA
Available Materials
Galvalume (22, 24 gauge)
Aluminum (.032, .040)
Copper (16 oz)
Available Widths
12” – 18”
Panel Options
Striations (Recommended)
Flat
Stress Ribs
* Factory applied Seam Sealant
Substrate Requirements
Can be installed over Solid Substrate
Minimum Roof Pitch
3:12
Underlayment
Ice & Water Shield (Recommened) or Synthetic Underlayment.
Finish
Kynar 500 (Fluoropolymer PVDF Coating)
Color Guide
Warranties
Testing
Panel Performance
UL 580 Class 90 (Uplift),
UL 790 (Class A Fire Rating)
UL 2218 (Impact Resistant)
ASTM 1592 (Uplift) Aluminum, Galvalume
ASTM 1646 (Water Penetration)
ASTM 1680 (Air Infiltration)
ASTM 2140 (Static Water Penetration)
Can be engineered to current ASCE 7 design standard
Sustainability
Energy Star
All of our metal panels are Energy Star certified and qualify for a federal tax credit. More Info ...
LEED
Our product can qualify for the following LEED Credits
- SS Credit 7.2 Heat Island Effect: Roof
- MR Credit 4.1 Recycled Content
- MR Credit 5.1 Regional Materials
Please contact Metal Roofing Systems to find out if your project will qualify for these LEED credits.
AIA Continuing Education Program
Metal Roofing Systems offers several courses approved by the AIA for architects. These courses are rich with information and provide architects with continuing education units or credits. Our courses encompass various topics including Standing Seam Metal Roof Systems, Metal Roofing Details and Warranties.
